Large Electric Motor Driven Centrifugal Pump / Techtop Motor Fire Fighting Pump Set NFPA20

Product Details

Place of Origin: China

Brand Name: CNP NM FIRE

Certification: UL /NFPA20

Model Number: SCF200-150-420

Payment & Shipping Terms

Minimum Order Quantity: 1set

Price: Negotiation

Packaging Details: Export Packing

Delivery Time: 60 Days

Payment Terms: L/C, T/T

Get Best Price
Highlight:

electric motor driven pump

,

electric motor driven water pump

Motor:
TECHTOP&UL
Driving:
Motor Driver
Controller:
Tornatech (UL/FM)
Capacity:
1250usgpm
Head:
220m
Impeller:
SS304
Motor:
TECHTOP&UL
Driving:
Motor Driver
Controller:
Tornatech (UL/FM)
Capacity:
1250usgpm
Head:
220m
Impeller:
SS304
Large Electric Motor Driven Centrifugal Pump / Techtop Motor Fire Fighting Pump Set NFPA20
  • Electic Motor Driven split case centrifugal pum 1250GPM 220m Techtop Motor NFPA20 Fire Fighting Pump

  • Split Case Motor Pump Set Product Details

Motor Pump Set
NM Fire Split Case Pump
Model SCF200-150-420 This Electric pump Set includes the pump(air relieve vlave , inlet & outlet gauges) , Motor, Control System,Commonbase.
Capacity 1250usgpm
Head 220m
RPM 2950rpm
Material:
Casing Ductile Cast iron
Impeller SS304
Shaft AISI 4340
Shaft sleeve SS304
Seal Gland packing
Wear ring Bronze
Bearing SKF
Engine: TECHTOP&UL
Model: 447TS350U2B
  300HP/50HZ/380V/3PH
Controller : Tornatech (UL/FM)
Model: GFY - 380 / 350 / 3 / 50 / A4

Large Electric Motor Driven Centrifugal Pump / Techtop Motor Fire Fighting Pump Set NFPA20 0

Standards


NFPA20, UL, FM, EN12845,CCCF

Performance Ranges

UL : Q: 100-750GPM H:70-152PSI

CCCF: Q:15-45L/S H:0.6-0.9Mpa

NFPA20: Q: 100-3000GPM H:40-200PSI
  • Application:

Large hotels, hospitals , schools,office buildings,supermarkets, commercial residential buildings, metro stations, railway stations, airports, kinds of transportation tunnels, petrochemical plants, thermal power plants, terminals, oil depots, large warehouses and industrial and mining enterprises, etc.

  • Five Advantages of CNP NM FIRE



①The late-mover advantage of products, we R&D better fire products than other Suppliers;


②Have the most complete and all series of fire pump models;


③Have listed diesel engines with self-owned brand--- NM FIRE;


④Understand the technology of fire- fighting products and fire- fighting system better than other competitors and have better services;


⑤Shorter delivery time.

Please contact us if you have any other requirements.

Thanks



Pumps applied for UL/FM certificates



our Listed pump and Standard fire pump
Pump: UL 448 FM1311
Engine: UL 1247 FM1333
Package according to NFPA20

In addition to the above models, there are many model UL/FM testing in process.

Looking forward to your enquiry.

  • FAQ



Q1.Do you have the UL-LISTED Fire Pump Sets?

Yes, We have the UL/FM and NFPA standard Fire Pump Sets.


Q2.I need your motor drive End-suction/Split-casing fire pump, what information shold I sent to you ?

Sir/Madam,you can privide the Capacity, Heed, Voltage and Frequncy,we will make the quotation for you,If you need Jockey Pump or other accessories, please tell us together.


Q3.If I need your Diesel Engine Drive End-suction/Split-casing fire pump, what information shold I sent to you ?

You can sent the Capacity Heed, Temperature and Altitude (temperature and altitude will affect the performance of diesel engines).If you need Jockey Pump or other accessories, please tell us Voltage and Frequncy or accessories together.


Q4.I need the UL/FM Vertical Tubine Fire Pump Set ,please sent me the price.

For the motor Diver Vertical Tubine Fire Pump Set: you shoul give us the Capacity, Heed, Voltage Frequncy and the tank deep.

For the Diesel Engine Drive Vertical Tubine Fire Pump Set:you should give us the Capacity, Heed and the tank deep.

If you need Jockey Pump or other accessories,please tell us together.



Large Electric Motor Driven Centrifugal Pump / Techtop Motor Fire Fighting Pump Set NFPA20 1
  • Service:

1. Reply within 24 hours.
2. High-quality products and the most reasonable price
3. Data and chemical technology support.

Large Electric Motor Driven Centrifugal Pump / Techtop Motor Fire Fighting Pump Set NFPA20 2
